Modux Micro Recessed Steplight

The Modux Micro Recessed Steplight is a miniature low-voltage dimmable outdoor washer, with optional canister.

The fixture is designed to be mounted either in the ground or wall to illuminate paths, or wash walls and steps.

Illumination is directed through the single facet 180° flange which projects light outwards and downwards to create an even wash across any surface.

Precision machined in marine grade 316 stainless steel or from copper the luminaire achieves IP68 water ingress rating for piece of mind.

The Cree 1 watt max LED can be easily replaced if required or substituted for a colour LED.

Diameter: Ø31.5mm
Depth: 21.5mm

Finishes

LED Colours








Specifications

Input Current: 60mA – 350mA max
Forward Voltage: 3Vf
Power: 1 Watt max
Efficacy: 70 Lm/W – Delivered from luminaire with unobstructed beam
Colours: 2700°K, 3000°K, 4000°K, 5000°K, Red, Green, Blue, Amber
CRI [3000°K]: 90 Minimum
Beam: 180°
Standards: IP68, LM79, CE, UL1838
Light Engine: Plug-in dimmable module equipped with Cree XT-E LED
Driver: Remote constant current driver required
Spec Sheet: Modux Micro Recessed Steplight.pdf

Modux Micro Range

Spike:

Recessed:

Dark Lighter:
