LuxR M4 Spotlight / RGBW
The LuxR M4 Spike Spot is a very small low-voltage dimmable outdoor spot light with a solid metal spike for installing into garden soil.
Precision machined in marine grade 316 stainless steel, copper or powdercoated aluminium, the luminaire achieves IP68 water ingress rating for peace of mind.
The Cree 4 watt max LED can be easily replaced if required. The optic is also simple to change if you wish to alter the beam width.
Precision machined in marine grade 316 stainless steel only LuxR is now able to offer their highly successful Modux Four range of luminaires with integrated Red, Green, Blue, White colour changing LED.
Eco Matt Powdercoat Colours [?]
LED Colours [?]
|Power:||4 Watt max|
|Colours:||2700°K, 3000°K, 4000°K, 5000°K|
|Beam:||12°, 26°, 36°, 74°|
|Lens:||Clear, Frosted, Hexcell louvre baffle|
|Standards:||IP68, LM79, CE UL1838|
|Light Engine:||Plug-in dimmable module equipped with Cree XT-E LED|
|Driver:||Remote constant current driver required|
Precision machined in marine grade 316 stainless steel only LuxR is now able to offer their highly successful Modux Four range of luminaires with integrated Red, Green, Blue, White colour changing LED.This system uses DMX signal protocol and DMX-spec cabling. The topology employed to connect the LuxR RGBW fittings together is a bussed (a kind of parallel arrangement) network. Technical notes on bussed networks can be found here. DMX is very fussy about cabling quality and we recommend you specify the required cable length for each luminaire ordered.
Finishes & LED Colours [?]
|Input Current:||12-24V DC, DMX Data +, DMX Data -, Data Shield|
|Power:||4.5 Watt max|
|Colours:||Neutral White 4000°K, Red, Green, Blue|
|Beam:||Spot (20°), Medium (34°), Oval (48°+24°)|
|Standards:||IP68, LM79, CE, USITT DMX512-A|
|Light Engine:||Plug-in dimmable module equipped with high power Cree 4×1 watt RGBW LED|
